6
W45-0536 / C / 09.06.06
figure 32
MANTLE CLEARANCES
0
3 4 7
8
9
11
13
1 2 5 6
7
10
12 H
E
I
G
H
T
M
A
N
T
L
E
MANTLE WIDTH
Combustible mantle clearance
can vary according to the man-
tle depth. Use the graph to
help evaluate the clearance
needed.
do NOT use the fireplace if any part has been under
water.
Call a qualified service technician immediATelY to
have the fireplace inspected for damage to the electri-
cal circuit.
if access to the control area is necessary before in-
stallation
, remove the access panel.
The access panel must be re-installed before operating
the unit.
it is necessary to hard wire this fireplace.
Permanently framing the fireplace with an enclosure, requires
the fireplace junction box to be hardwired.
This fireplace must be electrically connected and grounded in
accordance with local codes. In the absence of local codes,
use the current CSA C. CANADIAN ELECTRICAL CODE
in Canada or the ANSI/NFPA 70-996 NATIONAL ELECTRI-
CAL CODE in the United States.
ELECTRICAL CONNECTION
HARD WIRING CONNECTION
SCHEMATIC
IN OUT
OFF PI
LO
T
ON
AUXILIARY
DEVICE
FAN L2 L1
[HOT]
TP
TH
AUX
FAN
LINE
VAL
VE
MOTOR A UTO MAN
GAS
figure 33
STUD
2"
FIRESTOP
SPACER
COMBUSTIBLE
MATERIAL
2"
5"
3"
2"
6"
INSULATION
SLEEVE
1" GAP FROM INSULATION SLEEVE
2" GAP FROM VENTING
4"
TOP OF
UNIT
TOP OF
FIREPLACE
OPENING
11"
12" 10"
9"
8"
SPACER
STAND OFF
