Materials – Network Technologies RACKMUX-T15 User Manual
Page 6

NTI RACKMUX RACKMOUNT ANSI TERMINAL DRAWER
2
Options
•
LCD anti-glare protective glass shield - add a "G" to the model when ordering (i.e. RACKMUX-T15
G
)
•
Telco 2-post style mounting kit- order RL-T15-TEL
•
DC Power option- for use with 36-72VDC input- add “48V” to the part number
(i.e. RACKMUX-T1548V)
•
Numeric keypad option- for a separate 17-key numeric keypad, add “-N” to the part number (i.e. RACKMUX-T15-
N
)
See our catalog, visit our website at http://
www.networktechinc.com
, or contact an NTI sales representative at 800-742-8324 (800-
RGB-TECH) or 330-562-7070 for more details.
MATERIALS
Materials Supplied with this kit:
•
NTI RACKMUX-T15 Rack Mount ANSI Terminal Drawer
•
VEXT-1,5-MM 1-1/2 foot 15HD VGA male-male cable
•
9DF25DM-NUL-6 6 foot DB9 female to DB25 male null modem cable
•
IEC Power Cord, country specific
•
2 Keys for Lock
•
2 Rear Mounting Brackets w/nuts
•
8 #10-32x3/4” screws and cage nuts for mounting to a rack
