NTI RACKMUX RACKMOUNT ANSI TERMINAL DRAWER
25
5.2 Variable Values for Table 10 Commands
answer Up to 20 characters to define answerback message
attr Display Attributes attr Display Attributes
SPACE Space character p Dim
0 Normal q Dim and invisible
1 Blank r Dim and blink
2 Blink s Dim, blink, invisible
3 Blink and Blank t Dim and reverse
4 Reverse u Dim, reverse, invisible
5 Reverse and invisible v Dim, reverse, blink
6 Reverse and blink w Dim, reverse, blink invisible
7 Reverse, blink, invisible x Dim and underline
8 Underline y Dim, underline, invisible
9 Underline and invisible z Dim, underline, blink
: Underline and blink { Dim, underline, blink invisible
; Underline, blink, invisible | Dim, underline, reverse
< Underline and reverse } Dim, underline, reverse invisible
= Underline, reverse, invisible ~ Dim, underline, reverse blink
> Underline, reverse, blink DEL Dim, underline, reverse blink, invisible
? Underline, reverse, blink invisible
bank Font Bank
*a
bank Font Bank
*a
0 Font bank 0 2 Font bank 2
1 Font bank 1 3 Font bank 3
*a Holds predefined character set
baud Baud Rate baud Baud Rate baud Baud Rate baud Baud Rate
0 115200 4 19200 8 2400 < 200
1 76800 5 9600 9 1200 = 134.5
2 57600 6 7200 : 600 > 110
3 38400 7 4800 : 300 ? 50
bb...bb 32-byte character string defining bit pattern of character
bcolor Background Color bcolor Background Color
1 Black 5 Red
2 Bue 6 Magenta
3 Green 7 Yellow
4 Cyan 8 White
ccc
One-to three-decimal value of column relative to home
char
Character that replaces unprotected characters
col
See line/col
color color color color color color
1 Black 6 Magenta D Dim cyan
2 Bue 7 Yellow E Dim red
3 Green 8 White F Dim magenta
4 Cyan B Dim blue G Dim yellow
5 Red C Dim green H Dim white
cursor Cursor Display cursor Cursor Display
0 Cursor display off 3 Blinking line cursor
1 Cursor display on 4 Steady line cursor
2 Steady block cursor 5 Blinking block cursor
dir Direction
0 Normal
1 Remote
2 Local
