© National Instruments Corp. 27 NI 9219 Operating Instructions
4-Wire and 2-Wire Resistance,
10 K
Ω
4.1 1.3 0.8 0.3
4-Wire and 2-Wire Resistance,
1 K
Ω
7.1 1.8 1.2 0.7
4-Wire and 3-Wire RTD,
Pt 1000 7.6 1.7 1.1 0.4
4-Wire and 3-Wire RTD, Pt 100 10.8 1.9 1.9 0.9
Quarter-Bridge, 350 Ω 5.4 1.0 1.0 0.7
Quarter-Bridge, 120 Ω 5.4 1.0 1.0 0.7
Half-Bridge, ± 500 mV/V 3.8 0.5 0.5 0.2
Full-Bridge, ± 62.5 mV/V 5.4 1.0 1.0 0.8
Full-Bridge, ± 7.8 mV/V 30 4.7 4.7 2.3
Mode, Range
Conversion Time
High
speed
Best
60 Hz
rejection
Best
50 Hz
rejection
High
reso-
lution
