1-3
Getting Started
Connectors
Back panel
- 1 PS/2 mouse port
- 1 PS/2 keyboard port
- 1 1394 port (optional)
- 1 Optical SPDIF-out jack
- 1 DVI-D port
- 1 LAN jack
- 4 USB 2.0 ports
- 2 ESATA ports
- 6 flexible audio jacks
On-Board Pinheaders
- 3 USB 2.0 pinheaders
- 1 1394 pinheader (optional)
- 1 Front Panel Audio pinheader
- 1 CD-in pinheader
- 1 Serial port pinheader
- 1 TPM Module pinheader (optional)
- 1 SPDIF-out pinheader
- 1 Chassis Intrusion pinheader
TPM (optional)
- Supports TPM
Slots
- 2 PCI Express x16 slots compatible with PCIE 2.0 specification,
supports SLI mode
a. the mazarine PCIE x16 (PCI_E1) slot supports up to PCIE 2.0
x16 speed
b. the blue PCIE x16 (PCI_E3) slot is a special design that
supports up to PCIE 2.0 x8 speed
c. if you intend to use both PCIE x16 slots, please use them with
graphics cards in SLI mode and these two PCIE x16 lanes will
auto arrange from x16/ x0 to x8/ x8
- 1 PCI Express x 1 slot
- 2 PCI slots
Form Factor
- ATX (30.5cm X 24.4 cm)
M ounting
- 9 mounting holes
