NEC Versa P520 Disassembly Manual Page 30
14. To remove the antenna wires, unscrew the screws (16) and remove the tapes, which
hold the antenna wires on the LCD bottom cover.
Fig. 54: Removing the antenna wires
Disassembling the Optical drive
1. Remove the screws (5) and (7) from the drive assembly
Fig. 55: Removing the screws retaining the frame of the optical drive
2. Separate the drive and the plastic frame.
Fig. 56: Separating the optical drive from its frame
(16)=M2x3
(7)=(4)=M2x3
