CONNECTING WITH AUDIO SET
M When listening to sound in powerful AUDIO, while watching the picture on TV.
M Connect external input terminal of AUDIO to right & left sound output of TV signal.
RIGHT LEFT
M When connecting other equipment, please ensure you turn the main switch OFF to prevent any
damage to the equipment.
31
BROADCAST TRANSMISSION SYSTEMS IN EACH COUNTRY
Broadcast Transmission Systems in Each Country
Area
System
Color Sound
Country
Asia
M. E.
Oceania
China, etc.
Hong Kong
Iraq, Islamic Republic of lran, Lebanon, Saudi Arabia, etc.
Russian Federation, etc.
Myanmar, etc.
Australia
PAL B/G
PAL D/K
PAL I
SECAM B/G
SECAM D/K
NTSC M
PAL B/G(H)
Bahrain, Kuwait, Israel, Oman, Qatar, United Arab Emirates,
Yemen, etc.
India, Indonesia, Malaysia, Singapore, Thailand, etc.
CONNECTING DVD PLAYER
M When connecting the DVD player.
1. Prepare the connective plug for picture/sound.
2. Connect the DVD-Y output terminal of DVD player with the DVD-Y input terminal of TV.
3. Connect the Cr-DVD-Cb output terminal of DVD player with the Cr-DVD-Cb input terminal of TV.
4. Press the TV/VIDEO/DVD( ) button on the Remote Control to turn the TV into the DVD.
M You can connect the DVD PLAYER with VIDEO 1 INPUT TERMINALS, VIDEO3 INPUT TERMINALS or SCART
JACK(VIDEO2) input/output terminal.
LEFT
Y
Cb
Cr
Y Cb Cr
RIGHT
SOUND OUTPUT PICTURE OUTPUT
VIDEO 1 and DVD
is common.
This terminal are
possession of DVD.
M When connecting other equipment, please ensure you turn the main switch OFF to prevent any
damage to the equipment.
