1. Introduction
11
I
TEM
L
ABEL
D
ESCRIPTION
S
EE PAGE
:
10.
SC TRIGGER
When connected to the screen through a
commercially available cable, the screen de-
ploys automatically on start up of the
projector. The screen retracts when the pro-
jector is powered off (see notes below)
11.
S-VIDEO
Connect a commercially available S-video
cable from a video device
12.
POWER SWITCH
Turn on/off the projector
13.
AC IN
Connect the supplied power cable
14.
L/MONO, R
Connect RCA audio cables (not supplied)
from the input device right and left channels.
This audio jack is shared with S-Video input.
—
15.
VIDEO IN
Connect a composite video cable (not sup-
plied) from a video device to the yellow RCA
jack
16.
COMPONENT IN
(Y, Cb/Pb, Cr/Pr)
Connect a component video enabled device
17.
COMPUTER 2 IN
(R/Cr, G/Y, B/Cb,
H, V)
Connect RGBHV or Component signal from
computer or component video enabled device
18.
COMPUTER 1 IN
Connect a VGA cable (not supplied) from a
computer
19.
AUDIO IN (1)
Connect the audio cable (not supplied) from
the input device
—
20.
LAN
Connect a LAN cable (not supplied) from a
computer
21.
SERVICE
Connect the USB cable (not supplied) from a
computer. For service personnel only.
—
Note:
y
To use this feature, you must turn on the Screen Trigger function on OSD.
y
Screen controllers are supplied and supported by screen manufacturers.
y
Do not use this jack for anything other than intended use. Connecting the wired
remote control to the Trigger mini jack causes damage to the remote control.
