8. Specifications
136
u 15 Pin GPIO Control
Type: 15Pin D-SUB black female type
P
IN
N
O
. S
HORT
/O
PEN
F
UNCTION
14 SHORT
OPEN
EXTERNAL CONTROL MODE ON
EXTERNAL CONTROL MODE OFF
5 SHORT
OPEN POWER ON
POWER OFF
10 SHORT
OPEN PICTURE MUTE ON
PICTURE MUTE OFF
3 SHORT
OPEN SOUND MUTE ON
SOUND MUTE OFF
4, 8, 12, 11 11 12 8 4
OPEN OPEN OPEN OPEN COMPUTER1
OPEN OPEN OPEN SHORT VIDEO1
OPEN OPEN SHORT OPEN S-VIDEO1
OPEN OPEN SHORT SHORT COMPONENT
OPEN SHORT OPEN OPEN NOT AVAILABLE
OPEN SHORT OPEN SHORT COMPUTER2
OPEN SHORT SHORT OPEN NOT AVAILABLE
OPEN SHORT SHORT SHORT NOT AVAILABLE
SHORT OPEN OPEN OPEN COMPUTER3 (DVI)
SHORT OPEN OPEN SHORT NOT AVAILABLE
SHORT OPEN SHORT OPEN NOT AVAILABLE
SHORT OPEN SHORT SHORT NOT AVAILABLE
SHORT SHORT OPEN OPEN NOT AVAILABLE
SHORT SHORT OPEN SHORT NOT AVAILABLE
SHORT SHORT SHORT OPEN NOT AVAILABLE
SHORT SHORT SHORT SHORT NOT AVAILABLE
