1. Introduction

10

r

Terminal Panel Features

I

TEM

L

ABEL

D

ESCRIPTION

S

EE PAGE

:

1.

COMPUTER 3 IN

Connect the DVI cable (not supplied) from a
computer

31

2.

AUDIO IN (3)

Connect the audio cable (not supplied) from
the input device

—

3.

AUDIO OUT

Audio loop-thru

—

4.

MONITOR OUT

Connect to a monitor

—

5.

REMOTE 2

Connect the remote to the projector

16

6.

AUDIO IN (2)

Connect the audio cable (not supplied) from
the input device

—

7.

L/MONO, R
(COMPONENT)

Connect an RCA audio cables (not supplied)
from the input device right and left channels

—

8.

PC CONTROL

Installation control

128

9.

REMOTE 1

For external control

136
