NTI RACKMUX KVM Drawer with NODEMUX Switch

28

KEYBOARD FEATURES

The keyboard configuration of each CPU is saved in the NODEMUX switch. For example, if the CPU attached to Port 2 had
CAPS LOCK and NUM LOCK selected the last time that CPU was accessed, then they will automatically be set when that CPU is
accessed again.

Keyboard-To-Computer Translation


The NODEMUX switch enables a mixture of otherwise incompatible peripheral computer components to be connected together.
This is accomplished by performing keyboard-to-computer translations automatically (i.e. translate the Windows keyboard and
mouse to a SUN type CPU). The chart below shows the capabilities of the keyboard controlling certain CPU types.




Translation Capabilities

CPU

Device Sun

Mac Windows

RACKMUX Keyboard

Extra keys emulation

Power key emulation

Full functionality

Translation Tables

Use the charts below to type SUN’s additional keys with the RACKMUX keyboard:

SUN Extra Keys

RACKMUX keyboard

Sun Extra Keys

Space Bar + F1

Stop

Space Bar + F2

Again

Space Bar + F3

Props

Space Bar + F4

Undo

Space Bar + F5

Front

Space Bar + F6

Copy

Space Bar + F7

Open

Space Bar + F8

Paste

Space Bar + F9

Find

Space Bar + F10

Cut

Space Bar + F11

Help

Space Bar + F12

Compose

Space Bar + Up Arrow

Volume +

Space Bar + Down Arrow

Volume -

Space Bar + Left Arrow

Mute














Power Key Emulation

RACKMUX Keyboard

Mac CPU

Sun CPU

Space Bar + RT Arrow

Power

Power
