NTI RACKMUX KVM Drawer with NODEMUX Switch
14
Edit Mode (Con'td)
Function:
Keystroke:
Selects the last port on
the switch
Toggles between insert
and overstrike
Erase current character
Erase previous character
When finished making changes in Edit Mode, press and a prompt will appear to press either to save the changes or
to continue making changes without saving the changes just made. If the key is pressed instead of , all
changes made will be ignored and the display will return to the previous menu.
Search Mode
To enter Search Mode, type any alphabetical or numeric character when the Command Mode menu is on the monitor.
Search Mode enables the user to enter and maneuver through a list of CPU names. The CPU name best matching the characters
typed is selected. The list of CPUs may also be searched for a specific (or similar) name. The following commands are valid when
the search option has been invoked from Command Mode.
Function:
Keystroke:
Erase previous character
in search name
Move cursor one position to
the right in search name
Move cursor one position to
the left in search name
Select previous port
Select next port
Figure 13- Search Mode screen
Add a character to the search
string and select the best
matching CPU name
Exit Search Mode, return to
Command Mode
Switch to selected port
Insert (The character either gets inserted and the remainder of the name
gets shifted to the right, OR the current character gets overwritten.)
Delete
Backspace
Backspace
End
A-Z
0-9
(Type any alphabetical or numeric character)
Esc
Enter
