NTI RACKMUX KVM Drawer with NODEMUX Switch

23



Setup Menu


Selecting the Setup menu will bring up a screen in which the user can adjust

ƒ

OSD POSITION-the position of the OSD menus on the LCD display

ƒ

OSD TIME-the length of time the user can be idle before the OSD menu automatically exits (adjustable from 10

to 60 seconds)
ƒ

LANGUAGE-the language that the OSD menus will be presented in

With the item highlighted, (use the Up or Down arrow to move between them), press the Select button to choose the option to
adjust. Then use the Up or Down Arrow to adjust the setting as needed. Select EXIT when finished to return to the Main
Menu.













































OSD Image can be moved
to different points on the
display
