Nortel Networks ALTEON OS BMD00009 User Manual
Page 23

Alteon OS BBI Quick Guide
Configuring the Switch
23
BMD00009, November 2007
3.
View or make changes to the settings shown in the forms window. For example:
N
OTE
– Fields which must be configured for proper switch operations are highlighted on the
forms in
GREEN
type. Items which load other forms when selected are
underlined
.
4.
Submit, reset, or delete the form contents using buttons on the bottom of the form.
Submit
When selected, the form is sent to the switch. Any configuration changes are placed in
the “pending” state and do not take effect until you click the toolbar Apply command.
Reset
When selected, the form fields are reset to their last submitted values.
Delete
This button is available for configuration items that can be deleted. When selected, the
featured item is slated to be removed from the switch configuration database. The item is
not actually deleted, however, until you click the toolbar Apply command.
