(Revised 2010-11-15) 6
Key Features
Serial interface supports speeds up to 115.2Kbps
High performance 10/100BaseT Ethernet bridge
High performance processor runs ARP, DHCP client, ICMP, IP, PPP, TCP, Telnet, TFTP, HTTP server,
SMTP client, POP3 client, and PPP compression
Half duplex or full duplex support on the LAN interface
256 frame buffer for Ethernet bridging
Stores 10,000 MAC addresses
Automatically learns MAC addresses
Command line interface
The 102PC-SE operates on 10-30VDC
Housed in a steel ruggedized DIN rail enclosure, designed to withstand the most demanding industrial
applications, and have been fully tested and certified at industrial environmental extremes
PACKAGE CONTENTS
Please make sure the Serial over Ethernet package contains the following items:
1.
102PC-SE Protocol Converter
2. Product CD
Contact your carrier if any items are damaged.
Article I. INSTALLATION
Read the following warning before beginning the installation:
WARNING
Never install or work on electrical equipment or cabling during periods of lightning activity. Never connect
or disconnect power when hazardous gasses are present.
Disconnect the power cable before removing the enclosure top.
Do not operate the unit with the top cover removed
UNPACKING
Remove all the equipment from the packaging, and store the packaging in a safe place. File any damage
claims with the carrier.
CLEANING
Clean only with a damp cloth.
