NEC Versa M400/PB EasyNoteM5 M7 Disassembly Manual Page 6
Removing the Hard Disk Drive
To remove the hard disk drive, first remove the battery (see Removing the Battery ), then perform
the following steps:
1. Remove the screws as shown in Fig. 2
Fig. 2 Removing the Hard disk drive cover
2. Disconnect the HDD as shown in Fig. 3
Fig. 3 Disconnecting the hard disk drive
A = M2.5x7
Black
B = M2.5x5
Black
