Chapter 5 User Notes 37
Nortel Business Secure Router 222 — Fundamentals
2 Create a tunnel between the sites, as described above.
3 Create an H.323 trunk between the BCM50s, as per the BCM50 User Guide.
Configuring the router to act as a Nortel VPN Server (Client
Termination)
1 Under VPN / Client Termination,
a Enable Client Termination.
b Select authentication type and the encryption algorithms supported.
c If the clients are assigned IP addresses from a pool, define the pool, and
enable it.
2 Assuming a Local User Database is used for authentication,
a Add user name and password to the local user database as an IPSec user,
and activate it. If the hosts will be assigned a static IP address, enter the
address that will be assigned to the user.
Configuring the router to connect to a Nortel VPN Server (Client
Emulation)
1 Go to VPN / Summary, and select 'Edit'.
2 Select a connection type of Contivity Client, and fill in the web page with the
relevant data.
3 If Group authentication or On-Demand Client Tunnels are needed, click the
'Advanced' button to configure this.
Allowing remote management of a LAN-connected BCM50
1 Create the appropriate NAT server rules to add the BCM50.
Go to SUA/NAT / SUA Server, and create two server rules for HTTPS and
Element Manager access:
One named BCM_HTTPS, with port number 443, and the IP address of the
BCM50
One named BCM_EM, with the port number 5989, and the IP address of the
BCM50
