10
When the MDA is seated properly, the posts of the module
are visible in the holes of the MDA.
6
Insert the Phillips pan head screws through the holes
(
). Use the #1 Phillips screwdriver to tighten the
screws.
Figure 10 Tightening the screws
7
For each MDA installed, attach the supplied laser product
label to the front panel of the host module, immediately
below the MDA. Use the label that is printed in the
appropriate language for the country where you are installing
the equipment.
Note:
Tighten the rear screws first before you tighten the
front screws.
9883FA
