Figure 1-2. ni-imaq functions – National Instruments PCI-1428 User Manual
Page 12
Chapter 1
Introduction
1-4
ni.com
Figure 1-2. NI-IMAQ Functions
The NI-IMAQ driver software performs all of the functions required for
acquiring and saving images. The NI-IMAQ software does not perform any
image analysis. For image analysis functionality, refer to the
section in this chapter.
NI-IMAQ has both high-level and low-level functions for maximum
flexibility and performance. Examples of high-level functions include the
functions to acquire images in single-shot or continuous mode. An example
of a low-level function is configuring an image sequence, since it requires
advanced understanding of your IMAQ device and image acquisition.
NI-IMAQ internally resolves many of the complex issues between the
computer and your IMAQ device, such as programming interrupts and
DMA controllers.
NI-IMAQ is also the interface path between LabVIEW, LabWindows/CVI,
or a conventional programming environment and your IMAQ device. The
NI-IMAQ software kit includes a series of libraries for image acquisition
for LabVIEW and Measurement Studio, which contains libraries for
LabWindows/CVI, Visual C++, and Visual Basic. These libraries are
functionally equivalent to the NI-IMAQ software.
NI-IMAQ
Buffer Control
Acquisition
Camera Control
Lookup Table
Control
DAQ
Synchronization
Triggering
and Timing
