Vertical termination – Napoleon Fireplaces GD70NT-S User Manual
Page 8

8
W415-0434 / C / 03.24.05
REQUIRED
VERTICAL RISE
IN FEET
V
T
HORIZONTAL VENT RUN PLUS OFFSET IN FEET
H
T
The shaded area within the lines represents acceptable
values for H
T
and V
T
.
when
(H
T
) < (V
T
)
Simple venting configurations
FIGURE 9
For vent configurations requiring more than zero 90° elbow
(top exit) or one 90° elbow (rear exit), the following formu-
las apply:
Formula 1: H
T
< V
T
Formula 2: H
T
+ V
T
< 40 feet
See graph to determine the required vertical rise
V
T
for the
required horizontal run
H
T
.
0
5
1 0
15
2
0
40
10
20
30
3
VERTICAL TERMINATION
