20
W415-0434 / C / 03.24.05
BLOWER INSTALLATION
FIGURE 51
The Napoleon STARfire comes equipped with a blower, a
heat sensor, variable on/off speed control and a power cord.
The blower is thermally activated, so when it is turned on, it
will automatically start approximately 15 minutes after light-
ing the fireplace and will run for approximately 30 minutes
after the fireplace has been turned off. Use of the fan in-
creases the output of heat. Air, drawn in through the lower
louvre access door, is driven up the back of the firebox, and
exhausted as hot air between the upper louvres.
BLOWER SYSTEM
1. Open the lower control area.
2. Remove the control panel (3 screws).
3. Unplug the blower from the junction box or turn off the
power to the fireplace if hardwired.
4. Undo the fastener at the left side of the blower mounting
plate. The blower should now slide to the left, away from
the mounting tab.
5. Finally, disconnect the slip-on connectors at the motor of
the blower.
The wire harness provided in this kit is a universal har- The wire harness provided in this kit is a universal har- The wire harness provided in this kit is a universal har- The wire harness provided in this kit is a universal har- The wire harness provided in this kit is a universal har-
ness
ness ness ness ness. When installed, ensur . When installed, ensur . When installed, ensur . When installed, ensur . When installed, ensure tha e tha e tha e tha e that any e t any e t any e t any e t any ex x x x xcess wir cess wir cess wir cess wir cess wire is e is e is e is e is
contained, preventing it from making contact with any contained, preventing it from making contact with any contained, preventing it from making contact with any contained, preventing it from making contact with any contained, preventing it from making contact with any
mo
mo mo mo moving or hot objects ving or hot objects ving or hot objects ving or hot objects ving or hot objects.....
Drywall dust will penetrate into the blower bearings, Drywall dust will penetrate into the blower bearings, Drywall dust will penetrate into the blower bearings, Drywall dust will penetrate into the blower bearings, Drywall dust will penetrate into the blower bearings,
causing ir
causing ir causing ir causing ir causing irrrrrre e e e epar par par par para a a a ab b b b ble dama le dama le dama le dama le damag g g g ge e e e e. Car . Car . Car . Car . Care m e m e m e m e must be tak ust be tak ust be tak ust be tak ust be taken to en to en to en to en to
prevent drywall dust from coming into contact with the prevent drywall dust from coming into contact with the prevent drywall dust from coming into contact with the prevent drywall dust from coming into contact with the prevent drywall dust from coming into contact with the
blower or its compartment. Any damage resulting from
blower or its compartment. Any damage resulting from blower or its compartment. Any damage resulting from blower or its compartment. Any damage resulting from blower or its compartment. Any damage resulting from
this condition is not co
this condition is not co this condition is not co this condition is not co this condition is not cov v v v ver er er er ered b ed b ed b ed b ed by the w y the w y the w y the w y the war ar ar ar arrrrrranty polic anty polic anty polic anty polic anty policy y y y y.....
THERMODISC REPLACEMENT
The thermodisc is located to the left side of the lower con-
trol area, on a bracket and mounted beside the junction
box.
1. Unplug the blower from the junction box or turn off the
power to the fireplace if hardwired.
2. Remove the fastener. Pivot the bracket out from the fire-
box side.
3. Disconnect the slip-on connectors and remove the
thermodisc from the bracket.
FIGURE 54
BLOWER REPLACEMENT
B
A
FIGURE 52
C
FIGURE 53
