National Instruments NI USB-9229 - Manual

USER GUIDE AND SPECIFICATIONS
NI USB-9229/9239
4-Channel, 24-Bit Analog Voltage Input Module
This user guide describes how to use the National Instruments
USB-9229/9239 and lists the device specifications. In this document,
the NI USB-9229 and NI USB-9239 are referred to inclusively as the
NI USB-9229/9239.
Introduction
The NI USB-9229/9239 provides a USB interface for four channels of
24-bit simultaneous analog input with integrated signal conditioning. The
NI USB-9229/9239 consists of two components: an NI 9229/9239 module
and an NI USB-9162 carrier, as shown in Figure 1.
Figure 1. NI USB-9229/9239 Components
NI 9229/9239
NI USB-9162
NI USB-9229/9239
Hi-SP
eed USB Carrie
r
NI U
SB-9162
Hi-Speed USB Carrie
r
NI U
SB-9162
