28 Description and features
Meridian Mail
Meridian Mail comes preconfigured with preprogrammed extensions for
mailboxes. If the numbering plan is being modified, then the mailboxes can
be changed from any TTY used for system administration.
Set-Based Administration
The Set-Based Administration feature simplifies system installation and
administration by enabling a telephone to perform several administrative
and maintenance procedures. Use the Set-Based Administration feature
to perform tasks such as changing data for specific features related to
telephones or changing Calling Party Name Display on a telephone.
For more information about Set-Based Administration, refer to Set-Based
Administration (NN43001-603).
Multiple-terminal access
Small Systems allow access to up to five users for logging in, loading, and
executing overlays simultaneously. For example, if you have Expansion
Cabinets, users can access the system through the Main or Expansion
Cabinets at the same time.
Three SDI ports are provided on the main SSC card, while each Expansion
can be accessed through the three SDI ports on the SSC card of each IP
Expansion or the single SDI port available on the Fiber Receiver card of
each Fiber Expansion.
The advantage of multiple-terminal access is that it allows for more efficient
programming and maintenance of the system, especially when system
components are located up to 3 km (1.8 mi) apart.
Database Archive feature
The Software Installation program allows the archiving of databases that
you can subsequently use to load a customer site. This feature allows
you to configure multiple databases in an off-site lab environment. The
Database Archive feature also allows you to save databases on a PC Card
until the databases are required. You can load the database into the system
using the PC Card.
The off-site programming of databases is subject to all security keycode
restrictions. The off-site system must either use the security device that will
be installed in the system at the customer site, or have its own keycodes for
the feature set.
