8. Compatible Input Signal List
Signal Name
Horizontal Freqency
Vertical Frequency
[kHz]
[Hz]
Video(NTSC)
15.734
60
Video(PAL/SECAM)
15.625
50
Video (HDTV) 1920x1080i
33.75
60
Video (HDTV) 1280x720p
45
60
Video (HDTV) 1920x1080i
26.97
47.95
Video (HDTV) 1920x1080p
26.97
23.98
Video (HDTV) 640x480p
31.5
60
Video (HDTV) 1080x25p
28.13
25
Video (HDTV) 1080x30p
33.72
30
Video (HDTV) 1080x50i
28.13
50
APPLE MAC13"@67Hz
35.00
66.67
APPLE MAC16"@75Hz
49.72
74.55
APPLE MAC21"@75Hz
68.68
75.06
APPLE MAC23"@65Hz
69.87
65.18
APPLE MAC23"@74Hz
78.44
73.72
APPLE MAC28"@69Hz
85.21
68.66
SGI XGA@60Hz/70MHz
49.72
60.04
SGI SXGA@76Hz
81.97
75.97
Sun 1152x 900@66Hz
61.80
65.95
Sun 1152x 900@76Hz
71.71
76.05
Sun 1024x1024@61Hz
65.27
61.40
HP XGA@75Hz
62.94
74.93
VESA VGA@60Hz
31.46
59.93
VESA VGA@72Hz
37.86
72.81
VESA VGA@75Hz
37.50
75.00
VESA VGA@85Hz
43.27
85.01
VESA SVGA@60Hz
37.88
60.32
VESA SVGA@72Hz
48.00
72.19
VESA SVGA@75Hz
46.88
75.00
VESA SVGA@85Hz
53.67
85.06
VESA XGA@43Hz
35.52
86.96
VESA XGA@60Hz
48.36
60.00
VESA XGA@70Hz
56.48
70.07
VESA XGA@75Hz
60.02
75.03
VESA XGA@85Hz
68.68
85.00
VESA1152x 864@60Hz
54.35
60.05
VESA1152x 864@70Hz
63.99
70.02
VESA1152x 864@75Hz
67.50
75.00
VESA1152x 864@85Hz
77.49
85.06
VESA1280x 960@60Hz
60.00
60.00
VESA1280x 960@75Hz
75.00
75.00
VESA1280x 960@85Hz
85.94
85.00
VESA SXGA@43Hz
46.43
86.88
VESA SXGA@60Hz
63.98
60.02
VESA SXGA@75Hz
79.98
75.02
VESA SXGA@85Hz
91.15
85.02
VESA UXGA@48Hz
62.50
96.08
VESA UXGA@60Hz
75.00
60.00
VESA UXGA@65Hz
81.25
65.00
VESA UXGA@70Hz
87.50
70.00
VESA UXGA@75Hz
93.75
75.00
VESA UXGA@85Hz
106.30
85.00
Compatible Input Signal List
NOTE1: The VGA, SVGA, SXGA and UXGA signals are displayed with Advanced
AccuBlend. Digital input is possible with the shaded signals.
NOTE 2: UXGA can be supported for separate sync signal only.
NOTE 3: DVI digital signal can support a maximum resolution of XGA@85Hz.
