Connecting the ni 9481e, Figure 2. ni 9481e terminal assignments – National Instruments NI 9481E User Manual
Page 4
NI 9481E Operating Instructions and Specifications
4
ni.com
Connecting the NI 9481E
The NI 9481E has a 10-terminal detachable screw-terminal
connector that provides connections for four electromechanical
relay channels.
Figure 2. NI 9481E Terminal Assignments
CH0a
CH0b
CH1a
CH1b
CH2a
CH2b
CH3a
CH3b
NC
NC
0
1
2
3
4
5
6
7
8
9
0
3
