24 Chapter 3 Installing the IP Softphone 2050
NN40050-300 NN40050-300
Headset Type Select the type of headset that you have connected to the USB Headset Adapter.
Due to differences in headset construction, you may not get optimal audio performance when
using a headset that does not appear on the list. For optimal performance, always use one of the
headsets that appears on the Headset Type drop list.
Manual Override Select one of the available cadences to enable the Manual Override feature. For a description of
the available cadences, refer to
Table 3 on page 25 .
When Manual Override is enabled, you can manually turn on the external lamp using the IP
Softphone 2050 Smart Functions button on the USB Headset Adapter. For more information
about the IP Softphone 2050 Smart Functions button, refer to the IP Softphone 2050 Help.
Select None to disable the Manual Override feature.
Headset
Disconnect Select one of the available cadences if you want the external lamp to indicate when the headset is
disconnected from the USB Headset Adapter. For a description of the available cadences, refer to
Table 3 on page 25 .
Select None if you do not want the external lamp to indicate when the headset is disconnected.
Active Call Select one of the available cadences if you want the external lamp to indicate when there is an
active call on the IP Softphone 2050. For a description of the available cadences, refer to
Table 3
on page 25 .
If the USB Headset Adapter is selected as the Ringing Speaker, the external lamp also indicates
when there is a call ringing on the IP Softphone 2050. For information about setting the ringing
device, refer to
“Sound Devices” on page 22 .
Select None if you do not want the external lamp to indicate when there is an active call.
Note: If you select a cadence for Active Call, the external lamp also turns on or flashes when
another application uses the audio channel for the USB Headset Adapter.
Message Waiting Select one of the available cadences if you want the external lamp to indicate when the IP
Softphone 2050 message waiting light is on. For a description of the available cadences, refer to
Table 3 on page 25 .
The IP Softphone 2050 message waiting light normally indicates when there is a message
waiting. However, most systems also turn on or flash the message waiting light when the IP
Softphone 2050 is ringing.
Select None if you do not want the external lamp to indicate when the message waiting light is on.
Use backlight Select this check box to enable the backlight for the USB Headset Adapter buttons.
Clear this check box to disable the backlight for the USB Headset Adapter buttons.
Note: When you enable the backlight, you can use the state of the backlight to quickly determine
if the IP Softphone 2050 is running. When the backlight is on, the IP Softphone 2050 is running.
When the backlight is off, the IP Softphone 2050 is not running.
Configure Smart
Functions Click this button to set the options that are available when you press the Smart Functions button
on the USB Headset Adapter. For more information about the Smart Functions button, refer to the
IP Softphone 2050 Help.
Note: The External Lamp is an optional component. It normally is not included with the
USB Headset Adapter, and must be ordered separately. The external lamp also is known
as an “In-Use Indicator” lamp.
Table 2 USB Headset Adapter (Continued)
Attribute Description
