Setting Up Infrastructures 4-21
MA4000 Expense Management Cable Management User Guide - Issue 1
Backbone Source
Setting up the backbone source
Step 1 Click the Source tab. The Connection Location box is populated with the
selected source location.
Step 2 In the Connection Device Type box, click the appropriate radio button:
—Termination Hardware if this backbone starts on termination
hardware.
—Splice Enclosure if the backbone starts at a splice.
—Asset if the backbone starts at an asset.
Step 3 Click Save.
Backbone Source
Step 1 Click the Source tab. The Connection Location Select group box is
populated with the selected source location.
Step 2 The Connection Device Type frame contains radio buttons labeled
Termination Hardware, Splice Enclosure, or Asset.
Step 3 Click the Termination Hardware button if this backbone starts on
termination hardware.
Step 4 Click the Splice Enclosure button if the backbone starts at a splice.
Backbone Destination
The Destination tab functions similarly to the Source tab, except that
the Connection Location Select information is not populated.
Setting up the backbone destination
Step 1 Click the Set Location button in the Detail area to open the Location
window.
Step 2 Select the Destination from the tree. Building, Floor, and Space are
populated, unless you are connecting from an outdoor space, such as a
Utility Pole. In that case, only Space is populated.
Step 3 Click Accept.
Step 4 In the Connection Device Type box, click the appropriate radio button:
—Termination Hardware if this backbone ends on termination
hardware.
—Splice Enclosure if the backbone ends at a splice.
—Asset if the backbone ends at an asset.
Step 5 Click Save.
