4-8 Setting Up Infrastructures
MA4000 Expense Management Cable Management User Guide - Issue 1
Removing an Outdoor Space
Step 1
On the Cable Management Main Page, select Infrastructure on the
SETUP menu.
Step 2
Click on the campus name or icon. The Campus Info screen appears.
Step 3
Click the Space List radio button to show outdoor spaces.
Step 4
Click on the outdoor space you wish to remove and click on the Delete
button. If there is anything located in this space (termination hardware,
assets, etc.), a Cable Management warning box pops up: "The space
cannot be deleted until subordinate items are removed first."
Step 5
Click Save to complete the deletion. The building's name will be
removed from the Navigator Tree.
Faceplates
Every indoor or outdoor space may have a faceplate set up in Cable
Management.
Adding a Faceplate
Step 1
On the Cable Management Main Page, select Infrastructure on the
SETUP menu.
Step 2
Click to highlight the name of the space where you wish to add a
faceplate.
Step 3
The Space Info screen appears with the space name. Click the Add
button and add the name of the faceplate.
Step 4
Click Save to save the faceplate information. The new faceplate will be
added to the Navigator Tree.
Removing a Faceplate
Step 1
On the Cable Management Main Page, select Infrastructure on the
SETUP menu.
Step 2
Click to highlight the name of the space where you wish to delete a
faceplate.
Step 3
The Space Info screen appears with the faceplates listed. Click on the
Click the Delete button. If there is anything connected to the faceplate,
warning box pops up: "The space cannot be deleted until subordinate
items are removed first."
Step 4
Click Save to complete the deletion. The faceplate's name will be
removed from the Navigator Tree.
Example: Beyond a normal two- or four-port faceplate, Cable
Management is able to track several types of faceplates per the user's
discretion regarding how things are to be documented. An example
would be the MUTOA (Multi-User Termination Outlet Assembly).
