4-18 Setting Up Infrastructures
MA4000 Expense Management Cable Management User Guide - Issue 1
Editing the Key Sheet
The Key Sheet is used to describe the type of phone, type of phone
connection (line) from the phone switch, and voicemail information.
The Key Sheet tab appears when you are creating a Voice/Modem
horizontal link. The top bar contains fields that apply to the physical
telephone: Button Table, Speaker, Phone Type, and Call Display.
The form on the lower part of the tab contains information pertaining to
the actual connection.
Step 1 Click the Add button in the Detail area to enter Line, Extension, and
COS.
Step 2 You can check R (Ring) and Mail check boxes if applicable. Enter Fwd
To, Conditions, Pick, Hunt, and ACD.
Step 3 A comments box is provided for any additional information.
Step 4 Add as many lines as you want by clicking the Add button.
Step 5 Click Save when you are done.
Connecting a Horizontal Link to a Grounding Conductor
See “Grounding” on page 4-23 .
Splices
Adding Splices
Backbone cables between termination hardware often need to be spliced
together. The splice is housed in a container known as a closure.
Multiple splices can be housed within one closure.
Adding splices to the closure
Step 1 Highlight the space where you want to set up a splice. A backbone cable
may already exist, but this is not required to set up the splice.
Step 2 Click Splices in the drop-down field in the List View pane.
Step 3 Click the Add button in the Spreadsheet area. Place the cursor in the
Closure ID field.
Step 4 Enter the Closure ID.
