Confirming the CMOS Settings
NCR S16 Minitower Server Installing Network Operating System 2-3
Confirming the CMOS Settings
This section discusses the BIOS System Setup procedure.
To configure system settings in the BIOS Setup Utility, follow these steps:
1. Turn on power to the system. Observe that the memory test is executed.
Memory addresses should be rapidly displayed in the upper left-hand
corner of the screen. Ignore any memory size mismatch error displayed on
the screen.
2. Press Ctrl + Alt + Esc when prompted to enter the BIOS Setup Utility.
3. Select Basic System Configuration. To go from page to page, press Page
Down or Page Up.
4. Go to Page 2 and set parameters as follows (in the order indicated):
Hard Disk Block Mode Disabled
Advanced PIO Mode Disabled
Hard Disk Size > 504 MB Disabled
Hard Disk 32-Bit Access Disabled
Large Memory Support Mode Advanced
Memory Test Enabled
Auto Configuration Mode Disabled
Fast Boot Mode Disabled
Num Lock After Boot Enabled
Configuration Table Enabled
5. Return to Page 1, and set parameters as follows:
Diskette Drive A 1.44 MB 3.5-inch
Diskette Drive B None
IDE Drive 0 (xxx MB) None
IDE Drive 1 (xxx MB) None
IDE Drive 2 (xxx MB) None
