Chapter 2 Installation and Configuration
NI PXI-8108 User Manual 2-24 ni.com
Figure 2-7. Installing a DDR2 SO-DIMM in an NI PXI-8108 Controller
Hard Drive Recovery
The NI PXI-8108 controller ships with an OS Recovery CD that allows you
to reinstall your operating system onto your hard drive through an external
CD-ROM such as a USB CD-ROM drive. Boot the PXI controller using the
OS re-installation CD to recover the OS. You also may need to reinstall
other software after using the CD to recover the OS. For more information
on these tools refer to KnowledgeBase 2ZKC02OK at
ni.com/support .
Note Recovering the OS erases the contents of your hard disk. Back up any files you want
to keep.
1 DDR2 SO-DIMM Module 2 DDR2 SO-DIMM Socket
1
2
