Steps Instructions Explanatory Notes
1 Make sure the camera is turned off.
2 Remove the relay lens from the Mini35:
a. Locate the lock ring (b).
b. Rotate the lock ring (b) counter clockwise.
The relay is attached to the rear of the Mini35
via a bayonet type mount.
The lock ring (b) is the ring located in the front
of the relay lens, nearest to the body of the
Mini35.
3 Attach the relay lens onto the camera: a. Remove all filters, sunshades, adapter
rings, etc. before attaching the relay lens
directly onto the camera front lens
b. Eventually you need a rubber pad to grip
the protective cap, recessed deeply in the
hood
