System Kernel
CPU ........................................................ GeodeLink Control Processor
LX800 500 MHz
BIOS....................................................... Award 512 KB flash memory
South bridge ........................................... GeodeLink Control Processor
CS5535
VGA ....................................................... GeodeLink Control Processor
LX800 500 MHz
Ethernet .................................................. Realtek RTL8100BL;
IEEE 802.3u protocol compatible
Watchdog timer...................................... W83627 watchdog timer;
1.6 s timeout period
IDE ......................................................... 1 EIDE channel supports one
CompactFlash socket onboard
(Master) and one IDE interface
hard drive (Slave)
Note
COM1 and COM2 support only half-duplex (maximum baud rate: 115.2 Kbps).
LCD
Display type ........................................... TFT color LCD
Size (diagonal) ....................................... 12.1 in.
Maximum resolution .............................. 800
× 600 (SVGA)
Maximum colors .................................... 256,000
Pixel pitch (W
× H, mm)........................ 0.3075 × 0.3075
Viewing angle ........................................ 100°
Luminance (cd/m
²
) ................................. 340
Contrast ratio.......................................... 300
Operating temperature............................ 0 to 50 °C (32 to 122 °F)
(ambient)
