Viewfinder screen – Navman S-Series User Manual
Page 50
S-SERIES
50
Viewfinder screen
The Viewfinder screen allows you to take a NavPix and access the camera preferences.
To view the Viewfinder screen, press
on top of your Navman.
Note: Pressing
will not take a NavPix unless the Viewfinder screen is displayed.
Element
Description
Captures a NavPix.
Displays the Select an Album screen.
Returns you to the last screen viewed.
Displays the current lighting setting.
Tap to view lighting options.
Displays the brightness setting.
Tap to view brightness options.
Viewfinder
Displays the image as it will appear as a NavPix.
GPS icon- displays
green
when a GPS fix is established and
red
when a GPS fix is unavailable. To
indicate the reception strength of a GPS fix,
displays between one and four
green
vertical bars.
