BayStack Single Mode Fiber Media Adapter
The BayStack Single Mode Fiber Media Adapter is a modular
port supporting 10BASE-F signaling. It is designed to be
installed in the media adapter slot of any BayStack 10BASE-T
Hub.
The port conforms to Bay Networks proprietary standards for
Ethernet running over 9/125
µ
m single-mode fiber optic cable.
No IEEE or other international standards exist for this
configuration at this time.
Connection is made to the port using two straight-tip (ST)
connectors (Tx and Rx).
For more information about single-mode fiber optic cable
connection and limitations, see
” next in this guide.
6770
TX
Single Mode Fiber
RX
