Nortel Networks BayStack 893-862-B User Manual
Page 10

8
893-862-B
6. Verify the installation for the media adapter.
Observe for the installed media adapter that the respective
Media Adapter LEDs on the front panel of the hub light
according to Table 4.
For more information about interpreting media adapter
LEDs, refer to Chapter 1, “Quick Reference Information,” in
Using the BayStack 10BASE-T Hubs
.
Table 4. Media adapter status LEDs
Hub media
adapter LEDs
Media adapter status
Green
Link status is good, port not partitioned.
Amber
Link status is good, port is partitioned.
Off
Link status is bad or connection is not
present.
893-862-B SMF MDA Page 8 Monday, September 30, 1996 1:32 PM
