NTI UNIMUX SERIES USB DVI KVM SWITCH
1
INTRODUCTION
The UNIMUX-DVI-4 4-Port USB DVI KVM switch (UNIMUX) allows access to any four Windows, MAC, or SUN USB CPUs from
one USB keyboard and mouse and a DVI video-enabled monitor. Internal microprocessor circuitry allows all USB CPUs to be
booted simultaneously without keyboard error. Port selection is accomplished by front panel push buttons or commands typed on
the keyboard. Port lights and status LEDs continuously update on the front panel.
Available Option
• Switch models are available in 60 or 50 Hz, and 110 or 220V.
Types of User Input Devices Supported :
• USB keyboard with Windows layout
• USB keyboard with SUN layout
• USB keyboard with MAC layout
• USB Mouse - (up to 3 buttons)
• USB IntelliMouse (scrollwheel)
• USB Hub
• Mouse-Trak trackball
• Logitech, Kensington and Microsoft Wheelmouse or Trackball on Mac CPUs with special drivers
• Logitech Cordless Elite Duo keyboard and mouse
• Crystal Vision keyboard with touchpad
• Gyration keyboard/mouse
• NTI USB-PS/2 Adapter
• NTI USB-SUN Adapter
• DVI monitors
Types of CPUs Supported:
Any USB CPU supporting USB version 1.0 or above including:
• USB WINxx
• USB MAC
• USB SUN
MATERIALS
Materials supplied with this kit :
• NTI UNIMUX-DVI-4 USB DVI Video KVM Switch
• 120VAC or 240VAC at 50 or 60Hz-5VDC/2.0A AC Adapter
• Line cord, country specific
• Rack mount kit
• CD with pdf file of this manual
Materials Not supplied but REQUIRED:
• A USB-AB-xxM cable for each USB CPU being connected to the switch. Used for keyboard and mouse interface.
• A DVI-IS-xx-MM DVI-I digital and analog video interface cable to connect the DVI video from the CPU to the UNIMUX
where:
xx is the length of the cable in feet
MM indicates male-to-male connector
Cables can be purchased from Network Technologies Inc by calling (800) 742-8324 (800-RGB-TECH) in the US and Canada or
(330) 562-7070 (worldwide).
