Polycom KIRK Wireless Server 8000 Installation Guide
1–8
The unit configuration determines which plugs to use. Connect the plugs
according to the following table.
1 Plug a suitable power cord into the AC power adapter.
2 Insert the AC power adapter output connector firmly into the socket on
the KWS8000 so that the retention clip snaps to the plug.
3 Plug the AC power adapter into mains.
4 If more than one AC power adapter is to be connected, the primary
system power must be connected first, the rest does not have to be done
in any particular order.
5 When powering down the unit, ALL power connectors must be
unplugged to ensure the unit is completely powered off.
Two AC power adapters may be kept in the room behind the sliding doors at
the rear of the KWS8000. Installation must be done prior to connecting the
adapters to AC mains.
Table 1-5 Cable plugs overview
#
Nbr
BIF
Card
s
Redun-
dancy
SYS
PWR
Primary SYS
PWR
Backup 4+ BIF
PWR
Primary 4+ BIF
PWR
Backup BIF Card
Place-
ment
1 ≤ 4 No Connect No
Connect No
Connect No
Connect Slot 4-7
2 ≤ 4 Yes Connect Connect No
Connect No
Connect Slot 4-7
3
>
4
No Connect No
Connect Connect No
Connect Slot 0-7
4
>
4
Yes Connect Connect Connect Connect Slot 0-7
