Panasonic LN170WP38 - Manual

SHD00406BEK
This product complies with the RoHS Directive (EU 2002/95/EC). This product complies with the RoHS Directive (EU 2002/95/EC).
Publication date: November 2008 1
Light Emitting Diodes
LN170WP38
Round Type
φ 4.4 mm
 Absolute Maximum Ratings T
a
= 25°C
 Yellow Green
Parameter Symbol Rating Unit
Power dissipation P
D
90 mW
Forward current I
F
30 mA
Pulse forward current * I
FP
150 mA
Reverse voltage V
R
4 V
Operating ambient temperature T
opr
–25 to +85 ° C
Storage temperature T
stg
–30 to +100 ° C
Note) *: The condition of I
FP
is duty 10%, Pulse width 1 msec.
 Orange
Parameter Symbol Rating Unit
Power dissipation P
D
90 mW
Forward current I
F
30 mA
Pulse forward current * I
FP
150 mA
Reverse voltage V
R
3 V
Operating ambient temperature T
opr
–25 to +85 ° C
Storage temperature T
stg
–30 to +100 ° C
Note) *: The condition of I
FP
is duty 10%, Pulse width 1 msec.
 Electro-Optical Characteristics T
a
= 25°C
 Yellow Green
Parameter Symbol Conditions Min Typ Max Unit
Luminous intensity I
O
0.8 4.0 mcd
Reverse current I
R
V
R
= 4 V 10 µA
Forward voltage V
F
I
F
= 20 mA 2.2 2.50 V
Peak emission wavelength λ
P
I
F
= 20 mA 565 nm
Spectral half band width Δλ I
F
= 20 mA 30 nm
 Orange
Parameter Symbol Conditions Min Typ Max Unit
Luminous intensity I
O
0.5 2.5 mcd
Reverse current I
R
V
R
= 3 V 10 µA
Forward voltage V
F
I
F
= 20 mA 2.1 2.45 V
Peak emission wavelength λ
P
I
F
= 20 mA 630 nm
Spectral half band width Δλ I
F
= 20 mA 40 nm
 Lighting Color
 Yellow Green
 Orange
