— 21 —
Correction
• Insert the cassette with the window side up and the record
tab facing you.
• Check that a cassette tape is not already inserted. Press
EJECT 0.
• Check that the AC power cord is correctly connected to
an AC outlet.
• If the (Timer) indicator is lit on the display, press
POWER to cancel timer recording, then press EJECT
0.
• Check that the record tab on the back of the cassette is
not removed. (✈P.14)
Miscellaneous
A cassette cannot be inserted.
The cassette does not eject.
The cassette ejects when you press REC/OTR
¶, or when
you press POWER to set timer recording.
General
Mains voltage AC 110 – 240V
Mains frequency 50/60Hz
Power consumption Approx. 18 watts
Ambient temperature +5°C to +40°C
Relative humidity 10% to 80%
Dimensions Approx. 400(W) x 94(H) x 272(D) mm
Mass Approx. 3.1kg
Position for use Horizontal
Video output channel UHF E36 (adjustable between E28 — E60)
Possible number of TV channel 99
Number of pre-programmable memory blocks 8
Number of days in advance 365 or every day, or every week
Tuner
Aerial input B/G, D/K, I, SECAM K1
VHF L: 42 — 175 MHz
VHF H: 175 — 470 MHz
UHF: 470 — 870 MHz
CATV
Video
Input (VIDEO IN) 0.5 to 2.0 Vp-p, 75 ohms
Output (VIDEO OUT) 1.0±0.2 Vp-p, 75 ohms
Resolution Better than 240 lines
Signal/noise ratio Better than 43 dB
Audio
Input (AUDIO IN) –8 dBs, 50k ohms (0dBs=0.775 Vrms) – for RCA connector
–8 dBs, 10k ohms (0dBs=0.775 Vrms) – for SCART connector
Output (AUDIO OUT) –6 dBs, 1k ohms (0dBs=0.775 Vrms)
Accessories supplied Remote control unit
RF coaxial cable
Batteries – R6(SUM-3)/AA (only for checking operations)
SCART cable – RCA type (for VR388/55 only)
S
PECIFICATIONS
Design and specifications are subject to change without notice.
