Planar LC12 - Manual (Page 17)

Title: Product Specification: LC12 High-Bright Monitor Page 17 of 24
Document Number: 023-0284-01 Revision: A
6.2.1 Room Ambient Contrast
Minimum Contrast of the display under room ambient lighting conditions of 1076
LUX [100 fC] direct incident illumination, is > 90:1. Reference MIL-L-85762A (Table II).
6.2.2 High Ambient Contrast
Minimum Contrast of the display in a diffuse off-axis illumination of 86,080 LUX
[8,000 fc] and a specular on axis luminance (sky) of 6,853 cd/m 2 [2000 fL] is > 6:1.
Reference MIL-L-85762A (Table II).
6.3 Display Uniformity
Luminance Uniformity (U
L
) measured within 30 mm from edge of the display image area is + 40%
of the luminance measured at the center of the display screen.
6.4 Display Chromaticity
The metric used for color coordinate determination is the CIE 1976 UCS (Uniform Chromaticity
Scale) u’, v’ system.
Color determination is performed normal to the display in a dark room environment with
ambient light conditions less than 10 LUX [1fC] incident illumination.
The measured u’, v’ color coordinates at room temperature for White-light and the Red, Green,
and Blue primaries are listed for reference purposes only.
Color u? v? Perceived Color
Red 0.449 0.517 Red
Blue 0.144 0.299 Blue
Green 0.142 0.559 Yellowish-Green
White 0.215 0.489 Warm White
White color is concentrated around 5600 o K color temperature.
6.5 LCD Panel - Physical Image Characteristics
• The Monitor incorporates a matrix display with the following features:
• LCD Size: 307.5mm [12.11in] diagonal
• Active Area: 246.0mm [9.69in] by 184.5mm [7.26in]
• Pixel Format: 800 (H) x 600 (V) (1 full color pixel = R + G + B dots)
• Pixel Pitch: 0.3075mm [0.012in] horizontal x 0.3075mm [0.012in] vertical
• Pixel Arrangement: R,G,B vertical stripe
