20 www.pridemobility.com Elite Traveller Plus/Plus HD
OFF-BOARD BATTERY CHARGER
The off-board battery charger, when
plugged into the charger port (lo-
cated on the battery pack) and a stan-
dard electrical outlet, charges the Travel
Scooter’s batteries. See figure 9.
SHROUD PANELS
You can change the color of your Travel
Scooter by removing the colored plas-
tic shroud panel pieces and replacing
them with one of the other supplied sets.
The panels are held in place by a hook
and loop reusable fastener.
To remove the shroud panel pieces:
1. Use your finger to locate the push
hole behind each shroud piece.
2. Push through the hole to separate
the piece from the Travel Scooter.
See figures 10, 11, and 12.
NOTE: When installing the front
fender panel, make sure the tab at
the bottom of the panel is inserted
into the tab opening before secur-
ing the panel. See figure 10.
To reinstall the shroud pieces, place
each piece in its appropriate location
and push with slight pressure to secure
the reusable fastener.
Figure 9. Off-Board Battery Charger
I I I . Y O U R T R A V E L S C O O T E R
Figure 10. Front Fender Panel
Figure 12. Side Panel
PUSH HOLE
Figure 11. Rear Fender Panel
PUSH HOLE
PO
WER CHARGER
PLUGS INTO BATTERY PACK
PLUGS INTO STANDARD
ELECTRICAL OUTLET
TAB
LED’S
