Philips SAA7345 User Manual
Page 29
1998 Feb 16
29
Philips Semiconductors
Product specification
CMOS digital decoding IC with RAM for
Compact Disc
SAA7345
I
2
S timing
C
LOCK OUTPUT
SCLK (see Fig.23)
t
cy
output clock period
sample rate = f
s
−
472.4
−
ns
sample rate = 2f
s
−
236.2
−
ns
sample rate = 4f
s
−
118.1
−
ns
t
H
clock HIGH time
sample rate = f
s
166
−
−
ns
sample rate = 2f
s
83
−
−
ns
sample rate = 4f
s
42
−
−
ns
t
L
clock LOW time
sample rate = f
s
166
−
−
ns
sample rate = 2f
s
83
−
−
ns
sample rate = 4f
s
42
−
−
ns
t
su
set-up time
sample rate = f
s
95
−
−
ns
sample rate = 2f
s
48
−
−
ns
sample rate = 4f
s
24
−
−
ns
t
h
hold time
sample rate = f
s
95
−
−
ns
sample rate = 2f
s
48
−
−
ns
sample rate = 4f
s
24
−
−
ns
I
2
S timing (double speed)
C
LOCK OUTPUT
SCLK (see Fig.23)
t
cy
output clock period
sample rate = f
s
−
236.2
−
ns
sample rate = 2f
s
−
118.1
−
ns
sample rate = 4f
s
−
59.1
−
ns
t
H
clock HIGH time
sample rate = f
s
83
−
−
ns
sample rate = 2f
s
42
−
−
ns
sample rate = 4f
s
21
−
−
ns
t
L
clock LOW time
sample rate = f
s
83
−
−
ns
sample rate = 2f
s
42
−
−
ns
sample rate = 4f
s
21
−
−
ns
t
su
set-up time
sample rate = f
s
48
−
−
ns
sample rate = 2f
s
24
−
−
ns
sample rate = 4f
s
12
−
−
ns
t
h
hold time
sample rate = f
s
48
−
−
ns
sample rate = 2f
s
24
−
−
ns
sample rate = 4f
s
12
−
−
ns
SYMBOL
PARAMETER
CONDITIONS
MIN.
TYP.
MAX.
UNIT
