1998 Feb 16

23

Philips Semiconductors

Product specification

CMOS digital decoding IC with RAM for
Compact Disc

SAA7345

O

PERATION MODES

The motor servo has the operation modes as shown in Table 9 and is controlled by the motor mode register
(address 0001).

Table 9 Operation modes.

MODE

DESCRIPTION

Start mode 1

Disc is accelerated by applying a positive voltage to the spindle motor. No decisions are involved
and the PLL is reset. No disc speed information is available for the microcontroller.

Start mode 2

The disc is accelerated as in Start mode 1, however the PLL will monitor the disc speed. When the
disc reaches 75% of its nominal speed, the controller will switch to Jump mode. The motor status
signals are valid (register 0010).

Jump mode

Motor servo enabled but FIFO kept reset at 50%. The audio is muted but it is possible to read the
subcode.

Jump mode 1

Similar to Jump mode but motor integrator is kept at zero. Used for long jumps.

Play mode

FIFO released after resetting to 50%. Audio mute released.

Stop mode 1

Disc is braked by applying a negative voltage to the motor. No decisions are involved.

Stop mode 2

The disc is braked as in Stop mode 1, but the PLL will monitor the disc speed. As soon as the disc
reaches 12% of its nominal speed, the MOTSTOP status signal will go HIGH and switch the motor
servo to off mode.

Off mode

Motor not steered.

P

OWER LIMIT

In Start mode 1, Start mode 2, Stop mode 1 and Stop
mode 2, a fixed positive or negative voltage is applied to
the motor. This voltage can be programmed as a
percentage of the maximum possible voltage via the motor
output configuration register (address 0110) to limit
current drain during start and stop. The following power
limits are possible:

100% of maximum (no power limit)

75% of maximum

50% of maximum

37% of maximum.

L

OOP CHARACTERISTICS

The gain and cross-over frequencies of the motor control
loop can be programmed via the motor gain and bandwidth
registers (addresses 0100 and 0101). The possible
parameter values are as follows:

Gain: 3.2, 4.0, 6.4, 8.0 12.8, 16, 26.6 or 32.

Cross-over frequency, f

4

:

0.5,

0.7,

1.4 or

2.8 Hz.

Cross-over frequency, f

3

:

0.85,

1.71 or

3.42 Hz.

FIFO

OVERFLOW

If FIFO overflow occurs during Play mode (e.g. as a result
of motor shock), the FIFO will be automatically reset
to 50% and the audio interpolator is activated to minimize
the effect of data loss.
