1998 Feb 16
12
Philips Semiconductors
Product specification
CMOS digital decoding IC with RAM for
Compact Disc
SAA7345
DAC output
0 0 1 1
1 0 1 0
I
2
S CD-ROM mode
1 0 1 1
EIAJ; CD-ROM mode
1 1 0 X
I
2
S; 4f
s
mode
Reset
1 1 1 1
I
2
S; 2f
s
mode
1 1 1 0
I
2
S; f
s
mode
0 0 0 X
EIAJ; 16-bit; 4f
s
0 0 1 1
EIAJ; 16-bit; 2f
s
0 0 1 0
EIAJ; 16-bit; f
s
0 1 0 X
EIAJ; 18-bit; 4f
s
0 1 1 1
EIAJ; 18-bit; 2f
s
0 1 1 0
EIAJ; 18-bit; f
s
Motor gain
0 1 0 0
X 0 0 0
Motor gain G = 3.2
Reset
X 0 0 1
Motor gain G = 4.0
X 0 1 0
Motor gain G = 6.4
X 0 1 1
Motor gain G = 8.0
X 1 0 0
Motor gain G = 12.8
X 1 0 1
Motor gain G = 16.0
X 1 1 0
Motor gain G = 25.6
X 1 1 1
Motor gain G = 32.0
Motor bandwidth
0 1 0 1
X X 0 0
Motor f
4
= 0.5 Hz
Reset
X X 0 1
Motor f
4
= 0.7 Hz
X X 1 0
Motor f
4
= 1.4 Hz
X X 1 1
Motor f
4
= 2.8 Hz
0 0 X X
Motor f
3
= 0.85 Hz
Reset
0 1 X X
Motor f
3
= 1.71 Hz
1 0 X X
Motor f
3
= 3.42 Hz
Motor output configuration
0 1 1 0
X X 0 0
Motor power maximum 37%
Reset
X X 0 1
Motor power maximum 50%
X X 1 0
Motor power maximum 75%
X X 1 1
Motor power maximum 100%
0 0 X X
MOTO1, MOTO2 pins 3-state
Reset
0 1 X X
Motor Pulse Width Modulation (PWM) mode
1 0 X X
Motor Pulse Density Modulation (PDM) mode
1 1 X X
Motor Compact Disc Video (CDV) mode
REGISTER
ADDRESS
DATA
FUNCTION
INITIAL
