VoIP Link • On indicates the gateway is registered to an H.323 gatekeeper/SIP server, or,
in the case of direct routing, has at least one active VoIP connection.
• Off indicates the unit is not configured or registered, or has no active direct-
routed VoIP connection.
• Flashing green indicates that the unit is attempting to register or has failed
to register.
BRI Link/Sig On when L1 and L2 are active. Flash to follow signaling activity on D-Channel.
BRI B1/B2 Off indicates no active calls. Blinking when one or two B-channels are connected.
Ethernet Link • On when the Ethernet connection on the corresponding port has a
link indication.
• Flashes when data is received or transmitted at the corresponding Ethernet port.
Ethernet 100M • On when the Ethernet is connected to a 100Mb network
• Off when the Ethernet is connected to a 10Mb network.
Table 3. SmartNode 4630 LED definitions (Continued)
LED Description
