-10-
**Opation Card Set**
Zebra Indicator ON
Zebra 1 Level 70%
Zebra 2 Level 85%
Safety Zone I
EVF Output Y
Component R/G/B
Return
**Opation Card Set**
Zebra Indicator ON
Zebra 1 Level 70%
Zebra 2 Level 85%
Safety Zone I
EVF Output Y
Return
AW-PB301 AW-PB305
■ Option Card Setting Submenu
q Zebra Indicator [Zebra Indicator: OFF/ON]
ON:
Zebra indicator is shown in the viewfinder.
OFF: Zebra indicator is not shown in the viewfinder.
Note: If [CVBS] is selected at Item [EVF Output:
Y/CVBS] r, the zebra indicator will not be
shown.
w Zebra 1 Level Set [Zebra 1 Level: 70% to 109%]
Zebra 2 Level Set [Zebra 2 Level: 71% to 110%]
Zebra level 1 or 2 can be only when Zebra Indicator
q is at ON.
The zebra indicator can be shown in two steps
using two zebra patterns.
2 Level shows a finer zebra pattern than 1 level.
2 Level must be set at least 1% higher than 2 level.
e Safety Zone Select [Safety Zone: 1 to 5/OFF]
A type of safety zone to be shown in the viewfinder
can be selected.
No safety zone is shown if OFF is selected.
