IPD4-A2-GZ40-10 July 2005 7
3. Slide the Management Module Firmly into the Chassis. Tighten the fastening
screws on the management module faceplate.
Installing Your Interface Module(s)
Interface modules provide the subscriber connections for a 4000E BLC; up to four
interface modules may be installed in the 4000E (in slots 1–4). There are a variety
of models available for purchase. Refer to www.paradyne.com for further
information or contact your sales representative. Any combination of interface
module models may be installed in an 4000E as long as they are supported by the
model type and version number of your management module; refer to the Release
Notes for your particular management module model.
CAUTION
If a slot cover is removed from slots 2–4, it must be replaced with an uplink
module. DO NOT OPERATE A 4000E WITH AN EMPTY MODULE SLOT.
MANAGEMENT MODULE
Slot Module Guides
Fastening Screws
