crossover mode selector
input level control
low pass frequency control
high pass frequency control
bass boost level control
low level inputs
high level inputs
power LED
protection LED
power fuse
power terminals
speaker connections
when used with normal, full range systems, set this switch to “FULL.” If
you wish to use the internal crossover to power a driver of specific frequency
range, use the “LOWPASS” or “HIGHPASS” settings.
use this control to match the outputs of your head unit to the amplifier.
Starting with your head unit set at about the 2 o’clock position, increase
the amp level control until distortion begins to occur, and reduce slightly
from this point.
when the crossover selector switch is in “low pass” mode, this control
sets the upper frequency limit for audio program sent to the speakers.
when the crossover selector switch is in “high pass” mode, this control
sets the lower frequency limit for audio program sent to the speakers.
this control permits adjustment of the bass level up to an increase of
approximately 18 dB.
this amp features gold-plated RCA input jacks for high impedance input.
Use these with car stereo output which uses RCA-type connector cables.
if your car stereo lacks RCA-type output jacks, you may connect speaker
output leads to these input connectors.
this indicator is illuminated when power is applied.
this indicator is illuminated when built-in protection circuitry is activated.
the fuse protects the amplifier and your car’s electrical system from short
circuit conditions.
use these connectors to deliver power, ground and remote turn-on control
to the amplifier.
these terminals are 14K gold plated to guarantee high conductivity and
minimum signal loss.
Remote Bass Boost Plug in the Remote Bass Boost Control wire in here.(PLA-2150 without)
40 Watts x 2
60 Watts x 2
300 Watts x 2
15 Hz-30 KHz
250mV
2.5V
14.4V DC Neg. Ground (10.5-16V)
2-4 Ohms
4-8 Ohms
10K Ohms
100 Ohms
15A
281 x 59 x 209
11.06 x 2.32 x 8.25
75 Watts x 2
125 Watts x 2
500 Watts x 2
15A
281 x 59 x 280
11.06 x 2.32 x 11
PLA-2150 PLA-2250
75 Watts x 2
125 Watts x 2
600 Watts x 2
PLA-2350
100 Watts x 2
175 Watts x 2
700 Watts x 2
PLA-2450
20A
281 x 59 x 305
11.06 x 2.32 x 12
30A
281 x 59 x 343
11.06 x 2.32 x 13.5
frequency response
power supply voltage
output power @ 14.4v DC, 1KHz
RMS Power @ 4 Ohms
RMS Power @ 2 Ohms
Maximum Power Output
input sensitivity
low level inputs
high level inputs
maximum current draw
dimensions (W x H x L)
mm
inches
input impedance
low level inputs
high level inputs
matching speaker impedance
stereo mode
bridged mode
features and specifications
2 ch amp PLA-2150 • PLA-2250
PLA-2350 • PLA-2450
