10
input level control
low level inputs
high level inputs
power LED
power fuse
power terminals
speaker connections
use this control to match the outputs of your head unit to the amplifier.
Starting with your head unit set at about the 2 o’clock position, increase
the amp level control until distortion begins to occur, and reduce slightly
from this point.
this amp features gold-plated RCA input jacks for high impedance input.
Use these with car stereo output which uses RCA-type connector cables.
if your car stereo lacks RCA-type output jacks, you may connect speaker
output leads to these input connectors.
this indicator is illuminated when power is applied.
the fuse protects the amplifier and your car’s electrical system from short
circuit conditions.
use these connectors to deliver power, ground and remote turn-on control
to the amplifier.
these terminals are 14K gold plated to guarantee high conductivity and
minimum signal loss.
frequency response
power supply voltage
output power @ 14.4v DC, 1KHz
RMS Power @ 4 Ohms
Maximum Power Output
input sensitivity
low level inputs
high level inputs
30 Watts x 4
100 Watts x 4
15 Hz-30 KHz
250mV
2.5V
14.4V DC Neg. Ground (10.5-16V)
maximum current draw
dimensions (W x H x L)
mm
inches
2-4 Ohms
input impedance
low level inputs
high level inputs
10K Ohms
100 Ohms
matching speaker impedance
stereo mode
bridged mode
10A
281 x 59 x 235
11.06 x 2.32 x 9.25
features and specifications
4 ch amp PLA-419
